Description
Overview
Special design for low capacity to carry compression test such as triaxial, unconfined and etc.
Model NL 5019 X / 001. Key figures: Capacity 10 kN; Speed Range 0.0001 mm / min – 4.8 mm / min; Dimension (mm) 310 (L) x 380 (W) x 1100 (H); Approx. Weight 85 kg.
Applications & Test Methods
Universal Loading Frame is used for geotechnical and soil mechanics testing for earthworks, foundations and pavements. Read the method guides: Triaxial Test of Soil (UU, CU, CD), Unconfined Compression Test of Soil (ASTM D2166 / BS 1377-7). See the full soil laboratory equipment checklist. Browse all Soil testing equipment.
Technical Specifications
| Model Number | NL 5019 X / 001 |
|---|---|
| Capacity | 10 kN |
| Speed Range | 0.0001 mm / min – 4.8 mm / min |
| Platen Travel | 100 mm |
| Dimension (mm) | 310 (L) x 380 (W) x 1100 (H) |
| Approx. Weight | 85 kg |
| Power | 220 – 240 V, 50 / 60 Hz, 1 ph |
Why NL Scientific
- Manufactured in Malaysia to European standards, exported to 40+ countries
- Ready stock in a large warehouse for prompt delivery
- ISO/IEC 17025 accredited calibration laboratory
- Over 3,000 products for civil engineering and material testing
