Description
Overview
Automatic Triaxial Testing System (50kN / 3 Cell Version): the Advanced Pressure Volume Controllers (Built in version) is very easy to use and an ideal solution for the most modern laboratories. When used with Test Master Loader, data loggers and software, they can be controlled from a computer to form part of a complete automated triaxial testing system. They may also be used as stad alone units which are fully functioning with or without computer control. All the devices has its own computer interface. The devices come complete with internal volume and pressure transducers. Both channel are pre-calibrated, it can generate pressures up to 2000kPa (20 bar) and provides a maximum volume measurement of 100ml which is readable to 0.001ml.
Model NL 5019 X / 005. Key figures: Maximum Vertical Clearance 960mm; deformation with 100mm range at Power 110- 240V, 50/60 Hz, 550W; Weight 420 kg Sustainable; Pressure Resolution 1 kPa kPa per min. Precision.
Applications & Test Methods
Automatic Triaxial Testing System (50kN / 3 Cell Version) is used for geotechnical and soil mechanics testing for earthworks, foundations and pavements. It supports test procedures to ASTM D4767, ASTM D2850, ASTM D7181, BS 1377-7, BS1377-8. Read the method guide: Triaxial Test of Soil (UU, CU, CD). See the full soil laboratory equipment checklist. Browse all Soil testing equipment.
Optional Accessories
- De-airing Tanks
Technical Specifications
| Model Number | NL 5019 X / 005 |
|---|---|
| Maximum Vertical Clearance | 960mm |
| at high loads. | Horizontal Clearance 400mm |
| deformation with 100mm range at Power | 110- 240V, 50/60 Hz, 550W |
| accuracy of ± 0.003mm. | Dimension (mm) 1400mm (L) x 800mm (W) x 1500mm (H) |
| Weight | 420 kg Sustainable |
| Pressure Resolution 1 kPa | kPa per min. Precision |
| Volume Resolution 0.001 ml | Max. Volume capacity of 100ml, readable to 0.001ml. |
| Resolution : 1 kPa | Quiet operation. |
| Pore Pressure Measuring Range : 0 ~ 2 MPa | 1) Fast 16bit A/D converter |
| Accuracy : +/- 0.1% F.S. | 2) Serial port for computer control |
Compliance Standards
- ASTM D4767
- ASTM D2850
- ASTM D7181
- BS 1377-7
- BS1377-8
Why NL Scientific
- Manufactured in Malaysia to European standards, exported to 40+ countries
- Ready stock in a large warehouse for prompt delivery
- ISO/IEC 17025 accredited calibration laboratory
- Over 3,000 products for civil engineering and material testing
