Description
Overview
Analogue Compression Machine 2000 kN (E-Version): this compression testing machine mainly used for concrete rupture strength testing, cement, plastic sand, and red brick building materials compression resist testing. Widely used in metallurgy, building materials, space flight and aviation, colleges and universities, R&D institution lines. The test operation and data processing meets standard requirements.
Model NL 4000 X / 030. Key figures: Platen Dimension 250 x 220 mm; Piston Ram Diameter 250 mm; Product Dimension 1000(L) x 500(W) x 1200(H) mm; Packing Dimension 1140(L) x 550(W) x 1610(H) mm.
Applications & Test Methods
Analogue Compression Machine 2000 kN (E-Version) is used for fresh and hardened concrete testing in site and ready-mix laboratories. Read the method guides: Concrete Compression Test (EN 12390-3 / ASTM C39), Compression Testing Machine for Concrete, Concrete Flexural Strength Test (EN 12390-5 / ASTM C78). See the full concrete laboratory equipment checklist. Browse all Concrete testing equipment.
Technical Specifications
| Model Number | NL 4000 X / 030 |
|---|---|
| Platen Dimension | 250 x 220 mm |
| Piston Ram Diameter | 250 mm |
| Piston Ram Travel | 50 mm |
| Product Dimension | 1000(L) x 500(W) x 1200(H) mm |
| Packing Dimension | 1140(L) x 550(W) x 1610(H) mm |
| Product Weight | 650 kg |
| Power | 220~240 V, 750 W, 1 Ph, 50 / 60 Hz |
Why NL Scientific
- Manufactured in Malaysia to European standards, exported to 40+ countries
- Ready stock in a large warehouse for prompt delivery
- ISO/IEC 17025 accredited calibration laboratory
- Over 3,000 products for civil engineering and material testing
