Description
Overview
Clear, easy to read, sensitive & large LCD touch screen display of 155mm(W) x 85 mm(H) Maximum force hold facility with real time Force vs Time graph display. User input test number, age, weight & density for complete sample information. Real time speed indicator bar for better current speed reference for better control. Manual loading & conditional automatic loading for compression machines with suitable DC motor control system. Automatic conversion from kN to Mpa according to the chosen sample types.
Manufactured by NL Scientific — Asia’s leading manufacturer of civil engineering and material testing equipment, supplying laboratories, universities and road authorities worldwide. European-standard build quality with ISO/IEC 17025 accredited calibration support and ready-stock availability.
Technical Specifications
| Model Number | NL 4000 SC / U |
|---|---|
| Motor | 1 Hp D.C Gearmotor c/w Drive Unit 1 Hp D.C Motor c/w Drive Unit |
| Loading Range | 1 – 300 kN 301 – 3000 kN |
| Pump Pressure Range | 50 Mpa |
| Pressure Release Type | 3 Way Manually Release Valve |
| Pressure Transducer Range | 10 Mpa 50 Mpa |
| Approx Weight | 115 kg |
| Dimension | 420 (L) x 380 (W) x 1350(H) mm |
| Power | 220~240V, 750W, 2.5 Amps, 1Ph, 50/60 Hz |
Why NL Scientific
- European standard quality at competitive Asian pricing
- Large warehouse capacity with ready stock for prompt delivery
- ISO/IEC 17025 accredited calibration laboratory
- Over 3,000 product portfolio for civil engineering testing
